EUROLITE LED TMH-W480 Moving Head Wash Zoom

EUROLITE LED TMH-W480 Moving-Head Wash Zoom

EUROLITE LED TMH-W480 Moving Head Wash Zoom

Brand:

EUROLITE LED TMH-W400 Moving Head Wash Zoom

EUROLITE LED IP TMH-H760 Beam/Wash/Flower Effect

Features

12 powerful 40W 4in1 QCL RGBW LEDs (homogeneous color mixing); 12 individually controllable LEDs
Positioning within 540° PAN, 215° TILT
Auto-position correction (feedback)
Precise positioning (16-bit resolution)
Exact 16-bit resolution for dimmer
Motorized zoom; dimmer
Strobe effect
Integrated show programs
Direct color selection
Device cooling via temperature-controlled fans in the head; quiet fan in the base
Controllable via stand-alone; DMX; QuickDMX via USB (optional); W-DMX by Wireless Solution via USB (optional); CRMX by LumenRadio via USB (optional); music control via microphone; master/slave function
Flicker-free
Beam angle of 1° - 35°
Multicolor LCD display
Seamless color mixing; adjustable color change; animated patterns; customizable background colors
Power input and output for easy linking of up to 4 devices
Pre-programmed with Light Captain
Applications: Clubs/dance schools; weddings/gala/events; stage; theater
Usage options: Standing; flying
Power supply: 100-240 V AC, 50/60 Hz
Total power consumption: 475 W
Protection class: IP20
Protection rating: Class I
Type of lamp: LED lamp
Max. tilt movement: 215°
Max. pan movement: 540°
DMX channels: 11; 16; 18; 58
Cooling: Temperature-controlled fan in the head; quiet fan in the base
Projection: Flicker-free
Illuminance in Lux (lx): Narrow red (R) 1m: 10753 lx, 3m: 4966 lx, 6m: 1572 lx; Narrow green (G) 1m: 30231 lx, 3m: 12941 lx, 6m: 4189 lx; Narrow blue (B) 1m: 3586 lx, 3m: 2214 lx, 6m: 830 lx; Narrow cool white (CW) 1m: 29150 lx, 3m: 12657 lx, 6m: 4024 lx; Narrow all 1m: 66539 lx, 3m: 31156 lx, 6m: 10125 lx; Wide red (R) 1m: 2592 lx, 3m: 363 lx, 6m: 99 lx; Wide green (G) 1m: 7263 lx, 3m: 966 lx, 6m: 265 lx; Wide blue (B) 1m: 1368 lx, 3m: 188 lx, 6m: 51 lx; Wide cool white (CW) 1m: 6610 lx, 3m: 887 lx, 6m: 242 lx; Wide all 1m: 16995 lx, 3m: 2285 lx, 6m: 622 lx
Housing color: Black
Display type: Multicolor LCD display
Dimensions: Width: 39.0 cm; Depth: 27.0 cm; Height: 47.0 cm
Weight: 14.65 kg
Noise classification: Class 2 (light noise)
Special product: Not intended for room lighting in households
Purpose: Lighting for show effects

EUROLITE LED TMH-W480 Moving Head Wash Zoom

Experience the impressive performance of the EUROLITE LED TMH-W480 Moving Head Wash Zoom, a state-of-the-art wash light equipped with 12 powerful 40W RGBW LEDs. With a motorized zoom range from 1° to 35° and pixel control capabilities, this device offers homogeneous color mixing and creative pattern effects that will make your events shine.

The precise positioning with 540° PAN and 215° TILT ensures accurate light control, while the auto-position correction and 16-bit resolution for dimming and movement guarantee a smooth performance. The integrated strobe effect and pre-programmed show programs allow you to create impressive light shows with ease.

Thanks to its flexible control options via stand-alone, DMX, or wireless solutions, the TMH-W480 is ideal for clubs, dance schools, weddings, galas, and stage productions. With a robust housing and quiet fans, this device is suitable for both stationary and flying applications. Add an unforgettable brilliance to your event with the EUROLITE LED TMH-W480 Moving Head Wash Zoom!

Delivery areas

We only deliver to addresses within Switzerland and the Principality of Liechtenstein.

Shipping & delivery

Your parcels are usually dispatched via UPS 2 days after receipt of payment. You will receive a tracking number so that you can track the status of your delivery online at any time. Delivery is made without a signature.

If you would like a UPS shipment by registered mail, please contact us before placing your order, as this will incur additional costs.

Shipping costs & packaging

The flat-rate shipping fee is CHF 10.00 per order and covers both packaging and postage costs. To save shipping costs, we recommend combining several items in one order, as separate orders are charged individually. Your parcel is sent at your risk, but we always pack fragile goods with special care. Our shipping boxes are generously sized and offer optimum protection for your products.

Collection from our shop

You are also welcome to collect your ordered goods directly from our shop in [insert location XXXX].
