RELACART UR-222S 1-Channel UHF System 823-832 + 863-865 MHz
Features
- 1-Channel UHF System with frequencies 823-832 MHz and 863-865 MHz
- 10 groups with 90 fixed frequencies within a switching bandwidth of 11 MHz
- Pilot Frequency Squelch Technology to eliminate wireless RF interference
- Automatic Frequency Scan (AFS) for finding interference-free reception channels
- Infrared interface for quick and error-free synchronization between transmitter and receiver
- 2 detachable antennas (BNC) for use with the R-14D antenna splitter
- Up to 9 transmitters can be operated simultaneously without interference
- Multicolor LCD display
- Range of up to 80 m
- Desktop housing with rack mount option (19") available (1U)
- Power supply: 100-240 V AC, 50/60 Hz and 12V DC 1000 mA
- Signal-to-noise ratio: >105 dB
- Modulation: FM
- Material: Metal
- Color: Black
- Dimensions: Width 20 cm, Depth 26 cm, Height 4.4 cm
- Weight: 1.95 kg
RELACART UR-222S Single-Channel UHF System 823-832 + 863-865 MHz
The RELACART UR-222S is an affordable and reliable UHF system, ideal for daily use. With 90 channel presets across 10 groups and the capability to operate up to 9 channels simultaneously, this system offers maximum flexibility. The true diversity reception technology, combined with pilot tone and adjustable noise squelch, ensures outstanding transmission reliability.
Setting up the system is quick and straightforward, thanks to the auto-scan function and infrared synchronization between transmitter and receiver. The multi-color LCD display provides essential information such as battery status, RF signal strength, and frequency. With a range of up to 80 meters and the option to mount the system in a 19" rack, the UR-222S is perfectly suited for professional applications.
The package includes a receiver, two antennas, an external power supply, a microphone, a 1/4" cable, mounting brackets, and a user manual. Trust in the quality and performance of the RELACART UR-222S for your wireless audio applications!
