RELACART UR-222D 2-Channel UHF System 823-832 + 863-865 MHz
Features
- True Diversity Wireless Microphone System with Two Channels, 823-832 MHz + 863-865 MHz
- 2-Channel Multi-Frequency Wireless Receiver with Diversity Technology for Optimal Reception Quality
- 10 Groups with 90 Fixed Frequencies within 11 MHz Switching Bandwidth
- Pilot Frequency Squelch Technology Eliminates Wireless RF Interference
- Automatic Frequency Scan (AFS) for Finding Interference-Free Reception Channels
- Infrared Interface for Quick and Error-Free Synchronization between Transmitter and Receiver
- 2 Detachable Antennas (BNC) Allow Combination with Antenna Splitter R-14D
- Sturdy Metal Housing
- Multicolor LCD Display
- UHF 863 - 865 MHz Registration-Free and License-Free in Europe
- UHF 823 - 832 MHz Registration-Free and License-Free in Large Parts of Europe
- Range of Up to 80m in Line of Sight
- Desktop Housing
- (19") 48.3 cm Rack Mountable, 1U
- Up to 9 Transmitters Can Operate Interference-Free in Parallel
- Battery Status Indicator
- Type: Wireless Complete Set
- Weight: 2.89 kg
- Power Supply: 100-240 V AC, 50/60 Hz; 12V DC 1000 mA
- Total Power Consumption: 5 W
- Power Connection: Power Supply via Barrel Connector (M) with Included Power Supply Cable
- Number of Channels: 2
- Frequency Range: 45 - 18000 Hz
- Signal-to-Noise Ratio: >105 dB
- Diversity: Antenna Diversity
- Frequency Stability: ± 0.0005 %
- Modulation: FM
- Display Type: Multicolor LCD Display
- Material: Metal
- Color: Black
- Dimensions: Width: 41 cm; Depth: 26 cm; Height: 4.6 cm
RELACART UR-222D 2-Channel UHF System 823-832 + 863-865 MHz
Discover the RELACART UR-222D, a state-of-the-art true diversity wireless microphone system that offers exceptional sound quality and reliability. With two channels operating in the frequency range of 823-832 MHz and 863-865 MHz, this system is ideal for professional applications in the music and events industry.
The 2-channel multi-frequency receiver utilizes advanced diversity technology to minimize interference and ensure a stable connection. With 10 groups and 90 fixed frequencies within a switching bandwidth of 11 MHz, you can easily find interference-free reception channels, supported by automatic frequency scanning (AFS) and pilot tone squelch technology.
The robust metal housing and multi-color LCD display ensure durability and user-friendliness. With a range of up to 80 meters in line of sight, you can enjoy maximum freedom of movement. Additionally, up to 9 transmitters can be operated simultaneously, making the system particularly versatile.
The package includes the receiver, two antennas, mounting brackets, and a user manual. The RELACART UR-222D is the perfect choice for anyone seeking a reliable and powerful wireless microphone system.
