IMG STAGELINE 6-Channel Microphone Line Mixer

Features

• 6 stereo line inputs, 6 switchable balanced mono microphone inputs
• Adjustable auto talkover (-12 dB), switchable for channel 1 or channel 1+2
• Balance control for stereo input channels
• 3-band equalization
• 12V phantom power switchable
• LED VU meter, peak LED
• Master and record outputs
• Output switchable between stereo/mono
• Adjustable headphone output
• 482 mm rack mount (19"), 1 U
• Input channels: 6
• Number of Mic/Mono: 6
• Number of Stereo: 6
• Mic input: 1 mV/6.6 kΩ, 6 x 3-pin XLR, balanced
• Line input: 100 mV/10 kΩ, 6 x RCA L/R
• Master output: 1 V/600 Ω, 1 x RCA L/R, 1 x 3-pin XLR L/R, balanced
• Record output: 310 mV/600 Ω, 1 x RCA L/R
• Headphone: > 8 Ω, 1 x 6.3 mm jack
• Frequency range: 20-20,000 Hz
• THD (Total Harmonic Distortion): 0.1%
• Signal-to-noise ratio: 62 dB, unweighted
• Low frequency equalization: ±12 dB/50 Hz
• Mid frequency equalization: ±12 dB/1 kHz
• High frequency equalization: ±12 dB/10 kHz
• Talkover: -12 dB, manual
• Power supply: ~ 230 V/50 Hz/12 VA
• Voltage: ~ 230 V
• Frequency: 50 Hz
• Power consumption in operation: 12 VA
• Permissible operating temperature: 0-40 °C
• Width: 482 mm
• Height: 47 mm
• Depth: 208 mm
• Rack units (U): 1
• Weight: 2.8 kg
• Packaging dimensions (W x H x L): 0.255 x 0.09 x 0.53 m
• Gross weight: 3.76 kg
• Net weight: 2.985 kg
