OMNITRONIC DJP-900P MK2 Class-D Amplifier

Features

• Compact stereo mixer amplifier with player + Bluetooth, 2 x 460 W / 4 Ohm
• Integrated audio player with Bluetooth receiver
• Very lightweight and compact height due to integrated switch-mode power supply
• 2 operating modes adjustable (Stereo or Bridge/100V)
• 1 mono microphone input with volume control on the front panel
• Audio source switch
• Robust steel chassis with aluminum front panel
• Device cooling via fan
• Desktop housing (19") suitable for rack mounting, 1U
• Ideal for applications such as sports centers/gyms, restaurants, bars, and hotels
• Single-color 4-digit 7-segment LED display
• Power supply: 230 V AC, 50 Hz
• Total connection value: 140 W at 1/8 power
• Output power: 2 x 460 W RMS (4 Ohm), 2 x 240 W RMS (8 Ohm), Max. 260 W bridged (100 V), Max. 900 W bridged (8 Ohm)
• Frequency range: 20 - 20,000 Hz
• Signal-to-noise ratio: >100 dB
• Cooling: Fan
• Impedance: 4 Ohm; 8 Ohm; 16 Ohm; ELA technology 100V
• Chassis color: Black
• Circuit: Class D
• Rise times: >14 V/µs
• Damping factor: >300
• Controls: Power switch, source switch, tone control, volume control, operation mode switch (Stereo / Bridge/100V)
• Protection circuit: Soft start; Short circuit; Overheating; Overload; DC; VHF
• Status LED: Power
• Connections: Microphone via 1 x 3-pin XLR/6.35mm jack (W) combo socket, Line via 4 x stereo RCA, Line via 1 x 3.5 mm jack socket (stereo), Speaker via 1 x screw terminal, Rec. via 1 x stereo RCA
• Equalizer: Master: 1 x 2-band stereo control
• Input sensitivity: 1 V
• Material: Metal
• Dimensions: Width: 24.1 cm, Depth: 25.6 cm, Height: 4.45 cm
• Weight: 2.46 kg
• Audio player: USB + SD + Bluetooth
• Range: Bluetooth: up to 10m
• Frequency band: 2.4 GHz
• Music formats: MP3, WMA; WAV
• Compatible storage media: USB devices/SD cards max. 32GB (FAT 16/32)
