OMNITRONIC EM-650B MK2 Entertainment-Mixer

OMNITRONIC EM-650B MK2 Entertainment Mixer

Brand:

OMNITRONIC EM-550B MK2 Entertainment Mixer

Features

Multifunctional 5+2 Channel Mixer with 3 Zones, Black
5 input channels with recessed gain control on the rear panel, signal LED, and smooth channel fader
3 adjustable master outputs with 3-band EQ and 10-segment stereo LED level meter
(19") 48.3 cm rack mountable, 2U
Suitable for applications such as: Installations; Restaurants, Bars, and Hotels; Clubs/Dance Schools
Power Supply: 230 V AC, 50 Hz
Protection Class: Class II
Power Connection: Power cable with Euro plug (included)
Frequency Range: 20 - 20,000 Hz
Signal-to-Noise Ratio: >60 dB Line, >70 dB Phono
Total Harmonic Distortion: Line/Phono
Gain: Microphone 52 dB, Line 17 dB, Phono 53 dB
Chassis Color: Black
Zone Output: 3 adjustable zones
Controls: Power switch, adjustable talkover, source selector
Status LEDs: Signal, channel level display, master level display, peak, channel source; CUE, talkover, ON AIR, routing
Connections: Input: Microphone via 2 x 3-pin XLR/6.35mm combo jack (built-in version); Input: Line/Phono via 2 x stereo RCA; Input: Line via 8 x stereo RCA; Output: Master via 3 x 3-pin XLR; Output: Master via 3 x stereo RCA; Output: Rec. via 2 x stereo RCA; Output: Headphones via 1 x 6.3 mm jack (balanced)
Channels: Input Channel: 2 x Stereo with Line-Line/Phono switch via RCA, channel control via fader, 3-band EQ control, master bus routing switch, gain control, source selector, CUE switch; Input Channel: 3 x Stereo with Line-Line switch via RCA, channel control via fader, master bus routing switch, gain control, source selector, CUE switch; Microphone Channel: 2 x Mono via combo jack (XLR/Jack), channel control via rotary knob, ON AIR switch, master bus routing switch, talkover switch; Master Output: 3 x Stereo via XLR or RCA, channel control via rotary knob, 3-band EQ control; Rec. Output: 1 x Stereo via RCA, master bus routing switch; Headphone Output: 1 x Stereo via jack, channel control via rotary knob, cue mix function
Chassis Design: (19") 48.3 cm rack mountable, 2U
Dimensions: Width: 48.3 cm, Depth: 14.8 cm, Height: 8.9 cm
Weight: 3.10 kg

OMNITRONIC EM-650B MK2 Entertainment Mixer

The OMNITRONIC EM-650B MK2 is a multifunctional 5+2 channel mixer, ideally suited for various applications in restaurants, bars, hotels, as well as clubs and dance schools. With three adjustable zones and a compact 19" rack-mountable design (2U), this mixer offers excellent flexibility and user-friendliness.

Five input channels with recessed gain control on the rear, signal LED, and smooth channel faders ensure easy operation.
Three adjustable master outputs with 3-band EQ and a 10-segment stereo LED level meter allow for precise sound control.
The mixer features a variety of connections, including microphone and line/phono inputs, as well as master and headphone outputs, enabling seamless integration into your existing setup.

Included in the package are the mixer itself, a user manual, a power cable, and a RCA cable. With a frequency range of 20 to 20,000 Hz and a signal-to-noise ratio of over 60 dB for line and over 70 dB for phono, the EM-650B MK2 guarantees outstanding sound quality.
