OMNITRONIC EM-280 Entertainment Mixer

Features

• 8-channel stereo mixer with 2 adjustable zone outputs, 19"
• 1 additional XLR microphone input with level control on channel 1
• Nominal input level switchable between +4dBu and -10 dBV
• Signal and overload indicators on each channel
• 4-digit stereo level meters on both output buses
• (19") 48.3 cm rack mountable, 1U
• Suitable for applications such as: installations; restaurants, bars, and hotels; clubs/dance schools
• Power supply: 115/230 V AC, 50/60 Hz
• Total power consumption: 15 W
• Protection class: Class I
• Power connection: Power cable with protective contact plug (included)
• Device fuse: 5 x 20 mm, T 1 A replaceable fuse
• Frequency range: 20 - 20,000 Hz
• Signal-to-noise ratio: >92 dB Line, >65 dB Microphone
• Total harmonic distortion: Line
• Gain: Mic/Line 18 dB
• Chassis color: Black
• Controls: Ground lift switch
• Status LEDs: Power, Master level display, Signal, Clip
• Connections: Input: Line via 8 x 6.3 mm TRS (balanced), Input: Microphone via 1 x 3-pin XLR, Output: Master via 2 x 6.3 mm TRS (balanced), Output: AUX via 1 x 6.3 mm TRS (balanced), Output: Headphones via 1 x 6.3 mm TRS socket (stereo) built-in version, Output: Headphones via 1 x 3.5 mm TRS socket (stereo) built-in version
• Channels: Input channel: 1 x Mono + Stereo with Mic-Line switch via XLR or TRS, Channel control via rotary knob, Pre-Post switch, Gain control; Input channel: 7 x Stereo via TRS, Channel control via rotary knob, Pre-Post switch; Master bus input: 2 x Stereo via TRS, Routing Master bus switch; Master output: 2 x Mono + Stereo via XLR or RCA, Channel control via rotary knob, Stereo-Mono switch; Master bus output: 1 x Stereo via TRS; Headphone output: 1 x Stereo via TRS, Channel control via rotary knob, Routing Master bus switch
• Chassis design: (19") 48.3 cm rack mountable, 1U
• Dimensions: Width: 48.3 cm, Depth: 28.0 cm, Height: 4.4 cm
• Weight: 3.06 kg
